🧰 Technical Specifications
• Model: Ajax DoorProtect Jeweller
• Type: Wireless Opening Detector
• Communication Technology: Jeweller
• Wireless Frequency: 868.0–868.6 MHz
• Radio Communication Range: Up to 1,200 m in open space
• Communication Security: Encrypted two-way communication
• Detection Type: Reed switch magnetic contact
• Magnet Detection Distance:
• Small magnet: up to 1 cm
• Large magnet: up to 2 cm
• Alarm Signal Delivery Time: 0.15 s
• Additional Input: NC input for third-party wired detector
• Tamper Protection: Yes
• Anti-Spoofing Protection: Yes
• Battery Type: 1 × CR123A battery
• Battery Life: Up to 7 years
• Operating Voltage: 3V
• Protection Class: IP50
• Operating Temperature: -10°C to +40°C
• Operating Humidity: Up to 75%
• Available Colors: White / Black
• Dimensions: 90 × 20 × 20 mm
• Weight: 29 g
• Compatibility: Ajax Hub, Hub Plus, Hub 2, Hub 2 Plus, ReX, ReX 2
