🧰 Technical specifications
• Model: DHI-ASI3213A-W
• Type: Face Recognition Access Controller
• Verification methods: Face, IC Card, Password, Remote
• Card technology: 13.56 MHz IC Card / DESFire EV3
• Display: 4.3″ Capacitive Touchscreen LCD
• Screen resolution: 480 × 272
• Camera: 2 MP CMOS dual-lens camera
• WDR: DWDR
• IR illumination: Auto IR
• Face recognition distance: 0.3–1.5 m
• Face recognition height: 1.1–2.0 m
• Face recognition accuracy: 99.9%
• Face recognition time: 0.2 s
• Mask detection: Supported
• QR code reading: Supported
• QR code reading speed: 500 ms
• Wi-Fi: IEEE 802.11 b/g/n (2.4 GHz)
• User capacity: 3,000 users
• Face capacity: 3,000 faces
• Card capacity: 5,000 cards
• Password capacity: 3,000 passwords
• Administrator capacity: 50 administrators
• Record capacity: 300,000 records
• Communication protocols: TCP/IP, IPv4, RTSP, RTP, TCP, UDP, SIP, P2P, OSDP
• Reader interfaces: 1 × RS-485, 1 × Wiegand
• Network port: 1 × RJ45 10/100 Mbps
• USB port: 1 × USB 2.0
• Exit button input: 1 channel
• Door status detection: 1 channel
• Lock control: 1 channel
• Anti-passback: Yes
• Tamper alarm: Yes
• Duress alarm: Yes
• Intrusion alarm: Yes
• Door timeout alarm: Yes
• Illegal card alarm: Yes
• Multi-user authentication: Yes
• Real-time monitoring: Yes
• Web configuration: Yes
• Auto registration: Yes
• Power supply: 12 VDC, 1.5 A
• Power consumption: ≤18 W
• Operating temperature: -10°C to +40°C
• Operating humidity: 0%–90% RH
• Operating environment: Indoor
• Installation: Wall mount, 86 box mount, desk mount
• Dimensions: 115 × 118 × 27.1 mm
• Compatible with DSS Pro Platform, SmartPSS and DMSS
