🧰 Technical specifications
• Model: DHI-ICS1-W2(868)
• Type: Smart Plug
• Relay output: 1 × NO/NC relay output
• Relay rating: 100–240 VAC, Max. 16 A
• Indicator light: Multi-status LED indicator
• LED status indication:
• Flashing green: Pairing
• Solid green: Circuit closed
• Light off: Circuit open
• Button: Multi-function button (On/Off, Pairing, Factory Reset)
• Signal strength detection: Yes
• Remote update: Cloud update
• Wireless frequency: 868.0 MHz – 868.6 MHz
• Maximum RF power: 16.15 dBm
• Communication distance: Up to 1600 m in open space
• Communication mechanism: Two-way communication
• Encryption: AES128
• Frequency hopping: Yes
• Power supply: 100–240 VAC, 50/60 Hz
• Power consumption: 0.3 W
• Data monitoring: Yes
• Monitoring parameters: Current, Voltage, Temperature
• Current measurement range: 0–16 A
• Voltage measurement range: 0–250 V
• Internal temperature monitoring range: 0°C to +55°C
• Internal temperature accuracy: ±2% or ±2°C
• Protection functions: Overcurrent, Overvoltage, Overheating
• Output control modes: Bistable mode / Pulse mode
• Operating temperature: -10°C to +55°C
• Operating humidity: 10%–90% RH, non-condensing
• Storage temperature: -10°C to +55°C
• Storage humidity: 10%–90% RH, non-condensing
• Installation: Power strip / 2-pin socket
• Casing material: PC
• Dimensions: 52 × 52 × 82 mm
• Net weight: 83 g
• Certification: CE
