🧰 Technical specifications
• Model: K32LCD+
• Type: Hardwired LCD Keypad Module
• Display type: 32-character blue LCD display
• StayD mode: Supported
• Real-time zone alarm display: Yes
• Firmware upgrade: Via 307USB
• Status indication: StayD status LED
• Programming: Menu-driven installer and end-user programming
• Zone input: 1 keypad zone input
• Chime zones: Independently selectable
• One-touch buttons: 8 programmable action buttons
• Panic alarms: 3 keypad-activated panic alarms
• Backlight: Adjustable
• LCD contrast: Adjustable
• Scroll speed: Adjustable
• Communication bus: 4-wire expansion bus
• Compatibility: MG5000, MG5050, MG5075, Spectra SP Series V2.31+, SP4000, SP65 V4.90+
• Installation: Wall mount
• Certification: EN50131 Grade 2
• Application: Alarm system control, programming and status monitoring
