🧰 Technical specifications
• Model: PMD2P
• Type: Wireless PIR Motion Detector
• Detection technology: PIR
• Sensor type: Dual-element sensor
• Pet immunity: Up to 18 kg (40 lb)
• Detection range: 11 m × 11 m
• Center beam range: Up to 15 m
• Viewing angle: 88.5°
• Wireless range:
• 35 m with MG6250
• 70 m with MG5000, MG5050, MG5075 and RTX3
• Signal processing: Auto Pulse Signal Processing
• Temperature compensation: Automatic
• Sensitivity adjustment: High / Low selectable
• Alive software supervision: Yes
• Energy save mode: 3-minute energy save mode after two detections within a 5-minute period
• Tamper protection: Dual tamper mechanism (Wall/Cover)
• Mounting: Wall mount
• Optional accessory: SB469 Swivel-Mount Bracket
• Certifications: EN 300-220, EN 50131
• Application: Indoor residential and commercial intrusion detection
